Part # Type  Shielding  Voltage  AWG  # of Elements  Jacket Diameter  Applicable Specifications
45122 Pair  SupraShield (Premium Foil/Braid)  300  22  0.325  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
(Ctrl+Click if PDF doesn't appear)
 Diameters (In)
1) Component 1 2 X 1 PAIR
a) Conductor 22 (7/30) AWG Tinned Copper 0.030
b) Insulation 0.016" Wall, Nom. TPE 0.062
(1) Color Code Alpha Wire Color Code B
Pair Color Pair Color Pair Color
c) Pair 2/Cond Cabled Together
(1) Twists: 6.9 Twists/foot (min)
2) Cable Assembly 2 Components Cabled
a) Twists: 5.3 Twists/foot (min)
b) Core Wrap Nonwoven Polyester Tape, 25% Overlap, Min.
3) Shield: A/P/A Tape, 25% Overlap, Min.
a) Drain Wire 22 (7/30) AWG Tinned Copper
b) Braid Tinned Copper,70% Coverage, Min.
4) Jacket 0.045" Wall, Nom.,TPE0.325 (0.339 Max.)
a) Color(s) Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White
b) Ripcord 1 End 810 Denier Nylon
c) Print ALPHA WIRE-* P/N 45122 2PR 22 AWG
20237/21918 125C 300 V OR
CRU AWM I/II A/B 125C 300 V FT1
P-07-KA140023-MSHA CE ROHS
* = Factory Code
1) UL AWM/STYLE 20237 125°C / 300 VRMS
 PLTC 105°C
 AWM/STYLE 21918 125°C / 300 VRMS
2) CSA International C(RU) AWM I/II A/B FT1 125°C / 300 VRMS
 SUN RES (Black only)
4) CE:EU Low Voltage Directive 2006/95/EC
1) CE: EU Directive 2011/65/EU(RoHS2):
 This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C.
2) California Proposition 65:The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65.
Physical & Mechanical Properties
1) Temperature Range-50 to 125°C
2) Bend Radius 10X Cable Diameter
3) Pull Tension 32 Lbs, Maximum
4) Sunlight Resistance Yes
Electrical Properties(For Engineering purposes only)
1) Voltage Rating 300 VRMS
2) Mutual Capacitance17.4 pf/ft @1 kHz, Nominal
3) Ground Capacitance31 pf/ft @1 kHz, Nominal
4) Characteristic Impedance87 Ω
5) Inductance0.2 µH/ft, Nominal
6) Conductor DCR16.7 Ω/1000ft @20°C, Nominal
7) OA Shield DCR3.1 Ω/1000ft @20°C, Nominal
PackagingFlange x Traverse x Barrel (inches)
a) 1000 FT 18 x 12 x 8 Continuous length
b) 500 FT 12 x 12 x 3.5 Continuous length
c) Bulk(Made-to-order)
 [Spool dimensions may vary slightly]
a) Print legend will contain CSA SUN RES on black cables only.

Xtra-Guard® 4 - Extreme temperature capability handles hot, cold, spills High TemperatureLow TemperatureUltraviolet LightEMI Noise

  • Extended-temperature cable with a temperature range from -50°C to +125°C
  • Features a high-performance TPE insulation and jacket offering three times the low-temperature flexibility of ordinary PVC
  • Outstanding ultraviolet light stability in all jacket colors
  • UL Rated TC 600 V and PLTC 300 V for cable tray applications (except 24 AWG)
  • Pennsylvania Bureau Deep Mining Safety approved for mine-wide monitoring systems
  • Provides exceptional protection against EMI interference when Supra-Shield is specified
